Synology DiskStation DS620slim

Synology Synology

DS620slim

Chính hãng & Mới 100%

  • Form Factor: Tower
  • CPU: Intel Celeron J3355/64-bit/DualCore 2 burst up to 2.5 GHz
  • Memory: 2GB DDR3L (1 x 2GB) (Expandable: 6 GB (2 GB + 4 GB))
  • Drive Bays: 6 (HDD not included )
  • Hot swappable Drive: Yes
  • External Ports: RJ-45 1GbE LAN X 2; USB 3.0 X 3
  • Maximum IP cam (License required): 25 (including 2 Free License)
  • Warranty: 2 years

Xem chi tiết

Free Ship từ 2.000.000đ

Giao hàng trong vòng 24h

Thanh toán linh hoạt

Bảo mật thông tin khách hàng

Hotline 24/7 - 0868 505055

Mua thêm 2,000,000₫ để được miễn phí Giao hàng!
Hardware Specifications
CPU
CPU ModelIntel Celeron J3355
CPU Architecture64-bit
CPU FrequencyDualCore 2 burst up to 2.5 GHz
Hardware Encryption Engine (AES-NI)
Hardware Transcoding EngineH.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (3840 x 2160)); maximum frame rate per second (FPS): 30
Memory
System Memory2 GB DDR3L
Memory Module Pre-installed2 GB (2 GB x 1)
Total Memory Slots2
Memory Expandable up to6 GB (2 GB + 4 GB)
Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays6
Compatible Drive Type* (See all supported drives)
  • 2.5" SATA HDD
  • 2.5" SATA SSD
Maximum Internal Raw Capacity30 TB (5 TB drive x 6) (Capacity may vary by RAID types)
Maximum Single Volume Size108 TB
Hot Swappable Drive
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)
  • Expansion of the internal volume is only supported if the combined single volume size does not exceed the maximum limit of 108TB.
External Ports
RJ-45 1GbE LAN Port2 (with Link Aggregation / Failover support)
USB 3.0 Port2
File System
Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
NotesexFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth)121 mm x 151 mm x 175 mm
Weight1.4 kg
Others
System Fan80 mm x 80 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level*20.5 dB(A)
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter65W
AC Input Power Voltage100V to 240V AC
Power Frequency50/60Hz, Single Phase
Power Consumption*34.88 W (Access)
7.59 W (HDD Hibernation)
British Thermal Unit119.1 BTU/hr (Access)
25.92 BTU/hr (HDD Hibernation)
Temperature
Operating Temperature5°C to 40°C (40°F to 104°F)
Storage Temperature-20°C to 60°C (-5°F to 140°F)
Relative Humidity5% to 95% RH
Certification
  • EAC
  • VCCI
  • RCM
  • FCC
  • CE
  • BSMI
Warranty2 Years
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • Power consumption is measured when fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 17.2 dB(A); Temperature: 23.6˚C; Humidity: 58.2%.
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number64
Maximum iSCSI Target Number128
Maximum iSCSI LUN256
iSCSI LUN Clone/Snapshot, Windows ODX
SSD TRIM
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
  • RAID 6
Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
File Services
File ProtocolCIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections500
Maximum Concurrent CIFS/AFP/FTP Connections (with RAM expansion)1,500
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Account & Shared Folder
Maximum Local User Accounts2,048
Maximum Local Groups256
Maximum Shared Folder256
Maximum Shared Folder Sync Tasks8
Synology High Availability
Log Center
Syslog Events per Second400
Virtualization
VMware vSphere 6 with VAAI
Windows Server 2016
Citrix Ready
OpenStack
Add-on Packages (Learn more about the complete add-on package list)
Antivirus by McAfee (Trial)
Central Management System
Synology Chat
Maximum Users1,000
Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
Cloud Station Server
Recommended Number of Hosted Files500,000
Recommended Number of Concurrent Sync Clients500 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.
Document Viewer
Download Station
Maximum Concurrent Download Tasks80
exFAT Access (optional)
Synology MailPlus / MailPlus Server
Free Email Accounts5 (Licenses required for additional accounts)
Maximum Number of Concurrent Users50
Notes
  • The CPU and RAM usage were both under 80% when testing the maximum number of concurrent users.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Read-write SSD cache was enabled in 5-bay (and above) NAS models with 2 SSDs units installed.
  • The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers.
  • Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Media Server
DLNA Compliance
Moments
Facial Recognition
Subject Recognition
Auto Color & Rotate
Moments Select
Snapshot Replication
Maximum Snapshots per Shared Folder1,024
Maximum of System Snapshots65,536
Surveillance Station
Maximum IP cam (Licenses required)25 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)*750 FPS @ 720p (1280x720)
600 FPS @ 1080p (1920x1080)
350 FPS @ 3M (2048x1536)
250 FPS @ 5M (2591x1944)
120 FPS @ 4K (3840x2160)
Total FPS (H.265)*750 FPS @ 720p (1280x720)
750 FPS @ 1080p (1920x1080)
450 FPS @ 3M (2048x1536)
250 FPS @ 5M (2591x1944)
200 FPS @ 4K (3840x2160)
Total FPS (MJPEG)*450 FPS @ 720p (1280x720)
250 FPS @ 1080p (1920x1080)
160 FPS @ 3M (2048x1536)
130 FPS @ 5M (2591x1944)
NotesSurveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Synology Drive
Recommended Number of Hosted Files500,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Sync Clients450 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Exceeding the limits above may result in longer response time in file operations.
  • Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
Maximum Users400
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
Video Transcoding4K Group 1 (See more)
Maximum Transcoding Channel Number2 channel, 30 FPS @ 4K (4096 x 2160), H.264 (AVC)/H.265 (HEVC) or
2 channel, 30 FPS @ 1080p (1920×1080), H.264 (AVC)/H.265 (HEVC)/MPEG-2/VC-1
Virtual Machine Manager
Recommended Virtual Machine Instances(Learn more)
Recommended Virtual DSM Number (Licenses required)2 (including 1 Free License)
Notes
  • Virtual Machine Manager is not supported on hosts running Synology High Availability.
  • The specifications vary depending on system configuration and memory size.
VPN Server
Maximum Connections30
Environment & Packaging
EnvironmentRoHS Compliant
Packaging Content
  • Main Unit X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • Surveillance Device License Pack
  • D3NS1866L-4G DDR3 non-ECC SO-DIMM
  • VS360HD
  • VS960HD
